█ Electronics Manufacturing Technical Articles

Challenges for Step Stencils with Design Guidelines for Solder Paste Printing

The stencil printing process is one of the most critical processes in the electronic production. Due to the requirement: "faster and smaller" it is necessary to place components with different paste volume close together without regard to solder paste printing. In our days it is no longer possible to control the solder paste volume only by adjustment of the aperture dimensions. The requirements of solder paste volumes for specific components are realized by different thicknesses of metal sheets in one stencil with so called step stencils. The step-down stencil is required when it is desirable to print fine-pitch devices using a thinner stencil foil, but print other devices using a thicker stencil foil.

The paper presents the innovative technology of step-up and step-down stencils in a laser cutting and laser welding process. The step-up/step-down stencil is a special development for the adjustment of solder paste quantity, fulfilling the needs of placement and soldering. This includes the laser cutting and laser welding process as well as the resulting stencil characteristics and the potential of the printing process.

Credit: LaserJob

SMT Manufacturability and Reliability in PCB Cavities

First published in the 2012 IPC APEX EXPO technical conference proceedings. Considering technological advances in multi-depth cavities in the PCB manufacturing industry, various subtopics have materialized regarding the processing and application of such

Credit: AT&S

Printing of Solder Paste - A Quality Assurance Methodology

Solder paste printing is known to be one of the most difficult processes to quality assure in electronic manufacturing. The challenge increases as the technology development moves toward a mix between large modules and small chip components on large and densely populated printed circuit boards. Having a process for quality assurance of the solder paste print is fast becoming a necessity.

This article describes a method to ensure quality secured data from both solder paste printers and inspection machines in electronic assembly manufacturing. This information should be used as feedback in order to improve the solder paste printing process.

Credit: Ericsson AB

Step Stencil design when 01005 and 0.3mm pitch uBGA's coexist with RF Shields

Some of the new handheld communication devices offer real challenges to the paste printing process. Normally, there are very small devices like 01005 chip components as well as 0.3 mm pitch uBGA along with other devices that require higher deposits of solder paste. Surface mount connectors or RF shields with coplanarity issues fall into this category. Aperture sizes for the small devices require a stencil thickness in the 50 to 75 um (2-3 mils) range for effective paste transfer whereas the RF shield and SMT connector would like at least 150 um (6 mils) paste height. Spacing is too small to use normal step stencils. This paper will explore a different type of step stencil for this application; a "Two-Print Stencil Process" step stencil. Here is a brief description of a "Two-Print Stencil Process". A 50 to 75 um (2-3 mils) stencil is used to print solder paste for the 01005, 0.3 mm pitch uBGA and other fine pitch components. While this paste is still wet a second in-line stencil printer is used to print all other components using a second thicker stencil. This second stencil has relief pockets on the contact side of the stencil any paste was printed with the first stencil. Design guidelines for minimum keep-out distances between the relief step, the fine pitch apertures, and the RF Shields apertures as well relief pocket height clearance of the paste printed by the first print stencil will be provided.

Credit: Photo Stencil LLC

Solder Paste Deposition Project Report

INTRODUCTION: • The mixed technology on a PCB is creating unique challenges for board assemblers. Solder paste volume requirement for castle like component and miniature components vary widely. Approaches to solve these problems are: • Dual print • Printing/dispensing • Overprinting • Hybrid approach • Step stencil

Credit: iNEMI (International Electronics Manufacturing Initiative)

A Study of the Aperture Filling Process in Solder Paste Stencil Printing

Stencil printing has been the dominant method of solder deposition in surface mount assembly. With the development of advanced packaging technologies such as ball grid array (BGA) and flip chip on board (FCOB), stencil printing will continue to play an important role. However, the stencil printing process is not completely understood because 52–71 percent of fine and ultra-fine pitch surface mount assembly defects are printing process related (Clouthier, 1999). This paper proposes an analytical model of the solder paste deposition process during stencil printing. The model derives the relationship between the transfer ratio and the area ratio. The area ratio is recommended as a main indicator for determining the maximum stencil thickness. This model explains two experimental phenomena. One is that increasing stencil thickness does not necessarily lead to thicker deposits. The other is that perpendicular apertures print thicker than parallel apertures.

Credit: Lehigh University
