█ Electronics Manufacturing Technical Articles

Moisture Measurements in PCBs and Impact of Design on Desorption Behaviour

Moisture accumulates during storage and industry practice recommends specific levels of baking to avoid delamination. This paper will discuss the use of capacitance measurements to follow the absorption and desorption behaviour of moisture. The PCB design used in this work, focused on the issue of baking out moisture trapped between copper planes. The PCB was designed with different densities of plated through holes and drilled holes in external copper planes, with capacitance sensors located on the inner layers. For trapped volumes between copper planes, the distance between holes proved to be critical in affecting the desorption rate. For fully saturated PCBs, the desorption time at elevated temperatures was observed to be in the order of hundreds of hours. Finite difference diffusion modelling was carried out for moisture desorption behaviour for plated through holes and drilled holes in copper planes. A meshed copper plane was also modelled evaluating its effectiveness for assisting moisture removal and decreasing bake times. Results also showed, that in certain circumstances, regions of the PCB under copper planes initially increase in moisture during baking.

Credit: National Physical Laboratory

Controlling Moisture in Printed Circuit Boards

Moisture can accelerate various failure mechanisms in printed circuit board assemblies. Moisture can be initially present in the epoxy glass prepreg, absorbed during the wet processes in printed circuit board manufacturing, or diffuse into the printed circuit board during storage. Moisture can reside in the resin, resin/glass interfaces, and micro-cracks or voids due to defects. Higher reflow temperatures associated with lead-free processing increase the vapor pressure, which can lead to higher amounts of moisture uptake compared to eutectic tin-lead reflow processes. In addition to cohesive or adhesive failures within the printed circuit board that lead to cracking and delamination, moisture can also lead to the creation of low impedance paths due to metal migration, interfacial degradation resulting in conductive filament formation, and changes in dimensional stability. Studies have shown that moisture can also reduce the glass-transition temperature and increase the dielectric constant, leading to a reduction in circuit switching speeds and an increase in propagation delay times.

Credit: CALCE Center for Advanced Life Cycle Engineering

Impact of FPC Fabrication Process on SMT Reliability

The functionality of electronic devices continues to increase at an extraordinary rate. Simultaneously consumers are expecting even more and in ever smaller packages. One enabler for shrinking electronics has been the flexible circuit board that allows the circuit board to fit a wide variety of shapes. Flexible printed circuits (FPC) have the capability to be very thin and can have unpackaged components directly attached using surface mount technology (SMT) and flip chip on flex technologies. Bare die can also be thinned and attached very close to the circuit board. However one caveat of high density flexible circuit boards with thin die is that they can be very fragile. The use of back side films and underfill can protect the die making circuits more robust. For underfill to work well it requires good adhesion to the circuit board which can mean that flux residues under the die normally must be removed prior to underfilling.

Credit: Starkey Hearing Technologies

Drying printed circuit boards

The following aims lie behind the investigations described: The circuit board is an integrated structure made of metal and plastic. Like most integrated components enclosed in plastic, it absorbs water. When it is rapidly heated as, for example, in soldering technology temperature processes, it is a well known fact that the water will evaporate abruptly, leading to destruction. It is therefore essential that the circuit board be dried before these soldering processes. Circuit board manufacturers are extremely hesitant at providing instructions on drying their circuit boards. Information from the ZVEI [1] should also be regarded critically. The cardinal problem is the high temperature which is recommended for baking. If this is applied, the result is often de-lamination and distortion of the circuit boards. Corrosion and the formation of intermetallic phases of the metallic surfaces are also to be expected. The following investigates whether gentle drying at 45°C or 60°C and at low relative humidity achieves the same result as baking at high temperatures. The industry provides novel dry cabinets which are suitable for rapid drying at relative humidities below one percent.

Credit: TOTECH Canada N.A Inc

Drying and storage recommendation for printed circuit boards

Printed circuit boards, especially multilayer, flexible and rigid-flexible printed circuit boards, are extremely hygroscopic, i.e. they absorb and bind the moisture in the air. A dried polyimide film, for example, will have reached its moisture saturation level again after just a few hours.

Credit: ILFA GmbH

MOISTURE PHYSICS AND PROCESS OF DRYING OF PRINTED CIRCUIT BOARDS

The aim of this collection and interpretation is to develop an understanding of moisture in materials, especially in printed circuit boards, to know the effects on further processing and to be able to derive targeted corrective actions when moisture-related problems occur. In principle, the considerations are valid for all types of PCBs. Although these basic principles are of particular importance when working with flexible and rigid-flexible printed circuit boards; observing them can mean the difference between success or failure.

Credit: Wurth Elektronik GmbH & Co. KG
